Baumer MDRM 18U9501

Name: MDRM 18U9501
Brand: Baumer
SKU: MDRM-18U9501
Price: 156 PLN
Availability: InStock

SKUMDRM-18U9501

ManufacturerBaumer

CategoryIndustrial automation components

12-month warranty

Available (1-2 days): 10 units

Select Condition

Quantity

Net price (1 pc.):

156,00PLN

Before ordering, make sure the part fits your device.

Free consultation

Delivery

Trusted partners:

International shipping

Dedicated account manager

Real-time tracking

Description

The Baumer MDRM 18U9501 is a magnetic angle sensor designed for precise angular position measurement in industrial automation applications. This sensor offers a 160° linear angular range with a resolution of 0.09°, ensuring high accuracy in rotational measurements. It operates over a temperature range of -40°C to +85°C and features an IP67 protection class, making it suitable for harsh industrial environments. The sensor is housed in a cylindrical threaded brass nickel-plated casing with a 18 mm diameter, and its sensing face is made of PBTP material. It is powered by a 5 VDC supply and provides a voltage output signal ranging from 0.5 to 4.5 VDC. The sensor's response time is less than 4 ms, and it has a maximum current consumption of 10 mA without load. The maximum working distance is 5 mm when used with the magnet rotor MSFS, and it can tolerate axial misalignment up to 0.4 mm. This sensor is ideal for applications requiring precise angular position feedback in automated systems.

Specifications

Weight	1.36 kgs
Angular Range	160° linear °
Resolution	0.09°
System Accuracy	±0.25%
Operating Temperature Range	-40°C to +85°C
Protection Class	IP67
Housing Material	Brass nickel-plated
Sensing Face Material	PBTP
Supply Voltage	5 VDC
Output Signal	0.5 to 4.5 VDC
Response Time	<4 ms
Current Consumption (No Load)	10 mA
