Telemecanique ATV66D23N4

Name: ATV66D23N4
Brand: Telemecanique
SKU: ATV66D23N4
Price: 17021.74 PLN
Availability: InStock

SKUATV66D23N4

ManufacturerTelemecanique

CategoryIndustrial automation components

6-month warranty

Available (1-3 days): 1 units

Select Condition

Quantity

Net price (1 pc.):

17021,74PLN

Before ordering, make sure the part fits your device.

Free consultation

Delivery

Trusted partners:

International shipping

Dedicated account manager

Real-time tracking

Description

The Telemecanique ATV66D23N4 is a variable speed drive from the Altivar 66 series, designed for controlling asynchronous motors in industrial applications. This model offers a power rating of 18.5 kW (25 hp) and operates within a supply voltage range of 380 to 460 V, suitable for both 50 and 60 Hz frequencies. It provides a continuous output current of 33 A at 400 V and supports output frequencies up to 0.3 kHz. The drive features a nominal switching frequency of 2.5 kHz, with adjustable switching frequencies between 0.5 and 4 kHz, and up to 16 kHz with current derating. Communication is facilitated via an RS485 multidrop serial link supporting Modbus protocol. The device is housed in a NEMA 1 rated enclosure, ensuring protection against dust and water ingress. Dimensions are 415 mm in height, 234 mm in width, and 245 mm in depth, with a weight of 14 kg. This model has been discontinued as of December 31, 2001, with end-of-service on December 31, 2009.

Specifications

Product Type	Variable Speed Drive
Power Rating	18.5 kW (25 hp)
Supply Voltage	380 to 460 V
Continuous Output Current	33 A at 400 V
Output Frequency	Up to 0.3 kHz
Nominal Switching Frequency	2.5 kHz
Communication Protocol	Modbus
Enclosure Rating	NEMA 1
Dimensions	415 mm x 234 mm x 245 mm
Weight	14 kg
