Festo CAPC-F1-E-M12

Name: CAPC-F1-E-M12
Brand: Festo
SKU: CAPC-F1-E-M12
Price: 281.57 PLN
Availability: InStock

SKUCAPC-F1-E-M12

ManufacturerFesto

CategoryIndustrial automation components

12-month warranty

Available (1-2 days): 1 units

Select Condition

Quantity

Net price (1 pc.):

281,57PLN

Before ordering, make sure the part fits your device.

Free consultation

Delivery

Trusted partners:

International shipping

Dedicated account manager

Real-time tracking

Description

The Festo CAPC-F1-E-M12 is an electrical sub-base designed to facilitate decentralized installation of bus nodes CTEU on valve terminals or input modules equipped with the I-Port interface. This component is particularly beneficial in applications requiring M12 connection technology, offering two interfaces for enhanced connectivity. It enables the installation of valve terminals or other devices over distances up to 20 meters, providing flexibility in system design. Additionally, when paired with the accessory CAFM, the connection block can be mounted on a DIN rail, streamlining the installation process. Key specifications include dimensions of 50 mm in width, 148 mm in length, and 28 mm in height, with a fieldbus interface comprising two M12 sockets, each with 5 pins. The operating voltage range spans from 18 to 30 V DC, with a nominal operating voltage of 24 V DC. The device supports a maximum power supply of 4 A, ensuring reliable performance in demanding environments. Constructed with a polyamide housing, the CAPC-F1-E-M12 offers a degree of protection rated at IP65 and IP67, making it suitable for various industrial settings. The ambient temperature range for operation is between -5°C and 50°C, with a storage temperature range from -20°C to 70°C. The product weighs 85 grams and comes with a 20-meter cable length, providing ample reach for diverse installation scenarios. This component is RoHS-compliant, aligning with environmental standards.
