Festo CPV10-M1H-5LS-M7

Name: CPV10-M1H-5LS-M7
Brand: Festo
SKU: CPV10-M1H-5LS-M7
Price: 86.19 PLN
Availability: InStock

SKUCPV10-M1H-5LS-M7

ManufacturerFesto

CategoryIndustrial automation components

6-month warranty

Available (1-2 days): 14 units

Select Condition

Quantity

Net price (1 pc.):

86,19PLN

Before ordering, make sure the part fits your device.

Free consultation

Delivery

Trusted partners:

International shipping

Dedicated account manager

Real-time tracking

Description

The Festo CPV10-M1H-5LS-M7 is a 5/2-way monostable solenoid valve designed for efficient control of compressed air in industrial automation systems. Operating at a voltage of 24V DC, it features a valve size of 10 mm and a standard nominal flow rate of 400 l/min. The valve operates within a pressure range of -0.9 to 10 bar and is constructed with a piston gate design, ensuring reliable performance. It is equipped with a pneumatic spring return mechanism and has a degree of protection rated at IP65, making it suitable for various industrial environments. The valve's nominal width is 4 mm, and it utilizes a soft sealing principle. It offers flexible mounting options and includes a detenting manual override for manual operation. The valve is pilot actuated and supports both external and internal pilot air supply. Its flow direction is non-reversible, and it features overlap lap. The valve operates with a pilot pressure range of 3 to 8 bar and has a b-value of 0.4 and a c-value of 1.6 l/sbar. Switching times are 17 ms for on and 27 ms for off, with a duty cycle of 100% when used with holding current reduction. The electrical power consumption is 0.46 W, and it can handle maximum positive and negative test pulses of 1400 µs and 700 µs, respectively. The valve is designed for use with compressed air according to ISO 8573-1:2010 [7:4:4] and can operate in lubricated conditions if required. It has a corrosion resistance class of 2, indicating moderate corrosion stress. The valve is suitable for ambient temperatures ranging from -5°C to 50°C and has a product weight of 70 grams.
