Festo CPV14-M1H-5LS-1/8

Name: CPV14-M1H-5LS-1/8
Brand: Festo
SKU: CPV14-M1H-5LS-18
Price: 57.46 PLN
Availability: InStock

SKUCPV14-M1H-5LS-18

ManufacturerFesto

CategoryIndustrial automation components

6-month warranty

Available (1-2 days): 54 units

Select Condition

Quantity

Net price (1 pc.):

57,46PLN

Before ordering, make sure the part fits your device.

Free consultation

Delivery

Trusted partners:

International shipping

Dedicated account manager

Real-time tracking

Description

The Festo CPV14-M1H-5LS-1/8 is a compact 5/2-way solenoid valve designed for efficient control of compressed air in industrial automation systems. Operating at 24 V DC, it features a standard nominal flow rate of 800 l/min and is suitable for operating pressures ranging from -0.9 bar to 10 bar. The valve is constructed with a piston gate design and offers a pneumatic spring return mechanism. It boasts a degree of protection rated at IP65, ensuring dust-tight and water-resistant performance. The valve's nominal size is 6 mm, and it utilizes a soft sealing principle. Mounting is versatile, accommodating various positions. Manual override options include both detenting and non-detenting types. The valve is pilot actuated and supports both external and internal pilot air supply. Flow direction is non-reversible, and it operates with an overlap lap type. The pilot pressure ranges from 3 bar to 8 bar. The valve exhibits a b value of 0.42 and a c value of 3.2 l/sbar. Switching times are 25 ms for activation and 35 ms for deactivation. It operates with a 100% duty cycle when used with holding current reduction. Electrical power consumption is 0.65 W, with maximum positive and negative test pulses of 1400 µs and 400 µs, respectively. The operating medium is compressed air compliant with ISO 8573-1:2010 [7:4:4], and lubricated operation is possible when required. This valve is ideal for applications requiring reliable and efficient control of compressed air flow.

Specifications

Weight	0.09 kgs
Signal Type	21
Signal Level	21 V
Product Type	Valve
Weight	0.09 kg
Operating Voltage	24 V DC
Operating Pressure Min	-0.9 bar
Operating Pressure Max	10 bar
Flow Rate	800 L/min
Stopień ochrony	IP65
Mounting Position	Any
