Festo LRB-D-7-O-MINI

Name: LRB-D-7-O-MINI
Brand: Festo
SKU: LRB-D-7-O-MINI
Price: 97.69 PLN
Availability: InStock

SKULRB-D-7-O-MINI

ManufacturerFesto

CategoryIndustrial automation components

6-month warranty

Available (1-2 days): 1 units

Select Condition

Quantity

Net price (1 pc.):

97,69PLN

Before ordering, make sure the part fits your device.

Free consultation

Delivery

Trusted partners:

International shipping

Dedicated account manager

Real-time tracking

Description

The Festo LRB-D-7-O-MINI is a compact pressure regulator designed for precise control of compressed air systems. This mini-sized regulator features a directly actuated diaphragm mechanism, ensuring consistent outlet pressure through primary pressure compensation and secondary venting. The rotary knob with detent allows for secure adjustments, and the device is lockable to maintain set parameters. It operates within a pressure range of 0.5 to 7 bar (0.5 to 7 MPa) and supports operating pressures from 1 to 16 bar (0.1 to 1.6 MPa). The standard nominal flow rate is 1800 l/min, suitable for various industrial applications requiring reliable pressure regulation. The LRB-D-7-O-MINI is constructed with a die-cast zinc sub-base and housing, a PA operator panel, and NBR seals, all compliant with RoHS standards. It is designed for line installation and is compatible with G¼ pneumatic connections. The operating medium includes compressed air as per ISO 8573-1:2010 [7:4:4] and inert gases, with a medium temperature range of -10°C to 60°C and an ambient temperature range of -10°C to 60°C. The product weighs 250 grams.

Specifications

Weight	0.45 kgs
Flow Rate	1800
Measurement Range	0.5 - 7
Weight	0.25 kg
Flow Rate	1800 L/min
Pressure Regulation Range	0.5 - 7 bar
Operating Pressure	1 - 16 bar
Mounting Position	Any
Material of Sub-Base	Die-cast zinc
Material of Seals	NBR
Material of Housing	Die-cast zinc
