Festo MOFH-3-1/8

Name: MOFH-3-1/8
Brand: Festo
SKU: MOFH-3-18
Price: 143.66 PLN
Availability: InStock

SKUMOFH-3-18

ManufacturerFesto

CategoryIndustrial automation components

12-month warranty

Available (1-2 days): 1 units

Select Condition

Quantity

Net price (1 pc.):

143,66PLN

Before ordering, make sure the part fits your device.

Free consultation

Delivery

Trusted partners:

International shipping

Dedicated account manager

Real-time tracking

Description

The Festo MOFH-3-1/8 is a monostable 3/2-way solenoid valve designed for efficient control of compressed air in industrial automation systems. Manufactured by Festo, this valve features a plate seat design with a mechanical spring return, ensuring reliable operation. It has a nominal width of 5 mm and a construction width of 26 mm, making it suitable for applications where space is limited. The valve operates within a pressure range of 1.5 to 8 bar and has a standard nominal flow rate of 500 l/min, providing robust performance for various pneumatic tasks. Its G1/8 pneumatic working port allows for easy integration into existing systems. The valve is actuated electrically and requires a solenoid coil, which is ordered separately. It offers a manual override with detenting, allowing for manual operation when necessary. The valve is designed for pilot-controlled operation with a non-reversible flow direction and underlap lap type. It has a switching time of 9 ms for activation and 29 ms for deactivation, ensuring quick response times. The valve is constructed with a soft sealing principle and is rated IP65 for protection against dust and water ingress, making it suitable for use in harsh industrial environments. The operating medium is compressed air as per ISO 8573-1:2010 [7:4:4], and it can operate with oil lubrication if required. The valve has a storage temperature range of -20°C to 60°C and can handle medium temperatures between -10°C and 60°C, providing versatility across different operating conditions.

Specifications

Weight	0.91 kgs
Manufacturer	Festo
Measurement Range	1.5 - 8
Weight	0.24 kg
Operating Pressure	1.5 - 8 bar
Standard Nominal Flow Rate	500 l/min
Pneumatic Working Port	G1/8
Actuation Type	Electrical
Manual Override	Detenting
Flow Direction	Non-reversible
Stopień ochrony	IP65
Sealing Principle	Soft
Mounting Position	Any
Switching Time On	9 ms
Switching Time Off	29 ms
