Siemens 3NC1091

Siemens 3NC1091 3nc1091 product image 1
SKU3NC1091
ManufacturerSiemens
CategoryIndustrial automation components
6-month warranty
Available (1-2 days): 1 units
Select Condition
Quantity
1
Net price (1 pc.):
57,46PLN
Before ordering, make sure the part fits your device.
Free consultation
Delivery
Trusted partners:
DHLUPSTNTFedEx
International shipping
Dedicated account manager
Real-time tracking

Description

The Siemens 3NC1091 is a single-pole fuse switch disconnector designed for industrial applications requiring reliable overcurrent protection. It accommodates 10 x 38 mm fuse links and operates at a rated voltage of up to 690 V AC and 800 V DC, with a continuous current rating of 32 A. This device is suitable for use as a safety switch and is compliant with IEC 60947-3 standards, making it ideal for protecting power semiconductors in electronic installations, frequency converters, UPS systems, and motor soft starters. Its compact design, measuring 58 mm in height and 85 mm in depth, ensures easy integration into various systems. The 3NC1091 features screw-type terminals for conductor connections, supporting solid conductors ranging from 1.5 mm² to 25 mm². With a front-side protection class of IP20, it offers adequate safety for standard industrial environments. The device is RoHS compliant, reflecting Siemens' commitment to environmental standards. For detailed technical specifications and installation guidelines, refer to the official Siemens datasheet.

Specifications

Weight
0.01 kgs
Aluminium Weight
0
Argent Weight
0
Customs Tariff Code
85369095
Copper Weight
0
EAN
4011209570306.0
Quantity in Package
1
Part Number
5540
UPC
662643167511.0
Comparative Metals Coefficient
01.07.2006
eClass Version 9.1
27-37-14-01
Product Description
ROZŁĄCZNIK BEZPIECZNIKOWY DLA WKŁ. SITOR, 1-BIEG., 10X38, DO 32 A, 690 V AC
Compliance
Produkt zgdony z RoHS od: 01.07.2006
Configurable Product
False
Country of Origin
DE
ECCN
N
ETIM 7
EC001040
Group Classification Key
P310
List of Characteristics
LV10.1
Metals Coefficient
LHP-----
Packaging Length
80,00
Packaging Width
65,00
Packaging Height
18,00
Packaging Size
MM
Unit of Measure
ST
eClass 6
27-37-14-01
eClass 7.1
27-37-14-01
eClass 8
27-37-14-01
eClass Version 9
27-37-14-01
Product ID
3NC1091
AL Field
N
Article Number
3NC1091
Product Family
Ordering Data Overview
Catalog ID
LV10.1
Packaging Dimensions
2.559 x 3.15 x 0.709
Package Size Unit of Measure
Inch
Quantity Unit
1 Piece
Voltage Rating
690 V
Product Group
5540
Net Weight
0.112 lb
Packaging Quantity
1 pieces
Commodity Code
85369095
Current Rating
32 A
