Siemens 6ED1055-1HB00-0BA2

Siemens 6ED1055-1HB00-0BA2 6ed1055-1hb00-0ba2 product image 1
SKU6ED1055-1HB00-0BA2
ManufacturerSiemens
CategoryIndustrial automation components
12-month warranty
Available (1-2 days): 8 units
Select Condition
Quantity
1
Net price (1 pc.):
430,97PLN
Before ordering, make sure the part fits your device.
Free consultation
Delivery
Trusted partners:
DHLUPSTNTFedEx
International shipping
Dedicated account manager
Real-time tracking

Description

The Siemens 6ED1055-1HB00-0BA2 LOGO! DM8 24R expansion module is designed to enhance the capabilities of the LOGO! 8 modular PLC system. This module provides 4 digital inputs and 4 relay outputs, facilitating the integration of additional control points in automation applications. It supports both AC and DC input signals, accommodating a wide range of input types, including NPN configurations. The module operates with a supply voltage of 24 V AC or DC, offering flexibility in various industrial environments. It is mounted on a 35 mm DIN rail, occupying 2 spacing units, ensuring a compact and secure installation. The device is rated for an input voltage range of 20.4 V to 28.8 V DC and 24 V AC, with a line frequency range of 47 Hz to 63 Hz. The digital inputs are designed for AC/DC signals, with a maximum permissible quiescent current of 1.1 mA for signal '0' and a typical current of 2.63 mA for signal '1'. The module's relay outputs can handle a maximum switching capacity of 1,000 W for resistive loads, with an output current of 5 A for signal '1'. The device is compliant with RoHS standards, ensuring it meets environmental and safety regulations. Its IP20 protection rating indicates suitability for indoor use, providing adequate protection against solid objects larger than 12 mm but not against water ingress. This expansion module is ideal for applications requiring additional digital inputs and outputs, such as signal acquisition and relay-based control, thereby extending the functionality of the LOGO! 8 PLC system.

Specifications

Weight
0.45 kgs
Customs Tariff Code
85389091
EAN
4034106029449.0
Quantity in Package
1
Part Number
4071
UPC
887621847494.0
Configurable Product
False
Country of Origin
CN
ECCN
EAR99H
eClass 6
27-24-22-04
eClass 7.1
27-24-22-04
eClass 8
27-24-22-04
eClass Version 9
27-24-22-04
eClass Version 9.1
27-24-22-04
ETIM 7
EC001419
Group Classification Key
R131
List of Characteristics
STLOGO
Packaging Length
9,50
Packaging Width
7,00
Packaging Height
5,50
Packaging Size
CM
Product Description
LOGO! DM8 24R expansion module, PS/I/O: 24V/24V/relay, 2 MW 4 DI/4 DO, AC/DC/NPN input for LOGO! 8
Comparative Metals Coefficient
04.08.2014
REACH
Lead CAS-Nr. 7439-92-1; Lead monoxide (lead oxide) lblREACHCasNo7368
Unit of Measure
ST
Product ID
6ED1055-1HB00-0BA2
AL Field
N
Compliance
Produkt zgdony z RoHS od: 04.08.2014
