Siemens 6SL3210-1KE13-2UF2

Produktbild: Siemens 6SL3210-1KE13-2UF2 6sl3210-1ke13-2uf2, 1
SKU6SL3210-1KE13-2UF2
HerstellerSiemens
KategorieIndustrielle Automatisierungsteile
12 Monate Garantie
Verfügbar (1-2 Tage): 1 Stück
Zustand wählen
Menge
1
Nettopreis (1 Stk.):
1 773,00PLN
Prüfen Sie vor der Bestellung, ob das Teil zu Ihrem Gerät passt.
Kostenlose Beratung
Lieferung
Vertrauenswürdige Partner:
DHLUPSTNTFedEx
Internationaler Versand
Persönlicher Ansprechpartner
Sendungsverfolgung in Echtzeit

Beschreibung

The Siemens SINAMICS G120C (Part Number: 6SL3210-1KE13-2UF2) is a compact 3-phase AC drive designed for precise motor control in industrial automation applications. Operating within a voltage range of 380 to 480 V and a frequency of 47 to 63 Hz, it delivers a rated power of 1.10 kW (1.50 hp) with a low overload capacity of 150% for 3 seconds, and a high overload capacity of 200% for 3 seconds. The drive features an integrated filter class A, ensuring compliance with electromagnetic compatibility standards. Its I/O interface includes 6 digital inputs, 2 digital outputs, 1 analog input, and 1 analog output, facilitating versatile connectivity. The device supports fieldbus communication protocols such as PROFINET-PN and EtherNet/IP, enhancing integration capabilities. Designed for ambient temperatures between -10 to 40 °C (14 to 104 °F), it operates efficiently with an air cooling system using an integrated fan. The drive's compact dimensions (173 x 73 x 160 mm) and lightweight design (1.40 kg) make it suitable for space-constrained installations. With a degree of protection rated at IP20, it is intended for use in environments where protection against solid objects is required but not against water ingress. The SINAMICS G120C is ideal for applications requiring reliable and efficient motor control, such as conveyor systems, pumps, and fans, offering a balance between performance and compactness.

Technische Daten

Gewicht
1,36 kg
Produkt-ID
6SL3210-1KE13-2UF2
AL-Feld
N
Zolltarifnummer
85044095
Konformität
Produkt zgdony z RoHS od: 01.07.2006
Konfigurierbares Produkt
False
Ursprungsland
GB
EAN
4042948668795.0
ECCN
N
eClass 6
27-02-31-01
eClass 7.1
27-02-31-01
eClass 8
27-02-31-01
eClass Version 9
27-02-31-01
eClass Version 9.1
27-02-31-01
ETIM 7
EC001857
Gruppeneinstufungsschlüssel
R220
Liste der Merkmale
D11.1SD
Menge in der Verpackung
1
Verpackungslänge
225,00
Verpackungsbreite
270,00
Verpackungshöhe
85,00
Verpackungsgröße
MM
Produktbeschreibung
SINAMICS G120C RATED POWER 1,1KW WITH 150% OVERLOAD FOR 3 SEC 3AC380-480V +10/-20% 47-63HZ UNFILTERED I/O-INTERFACE: 6DI, 2DO,1AI,1AO SAFE TORQUE OFF INTEGRATED FIELDBUS: PROFINET-PN PROTECTION: IP20/ UL OPEN TYPE SIZE: FSAA 173X73X178(HXWXD) EXTERNAL 24V
Teilenummer
5673
Vergleichender Metallkoeffizient
01.07.2006
REACH
Lead CAS-Nr. 7439-92-1; Lead monoxide (lead oxide) lblREACHCasNo7368; 4,4'-isopropylidenediphenol (Bisphenol A, BPA) CAS-Nr. 80-05-7; Diboron trioxide lblREACHCasNo3950
Maßeinheit
ST
UPC
804766242236.0
