Wago 222-412

Produktbild: Wago 222-412 222-412, 1
SKU222-412
HerstellerWago
KategorieIndustrielle Automatisierungsteile
12 Monate Garantie
Verfügbar (1-2 Tage): 1 Stück
Zustand wählen
Menge
1
Nettopreis (1 Stk.):
44,95PLN
Prüfen Sie vor der Bestellung, ob das Teil zu Ihrem Gerät passt.
Kostenlose Beratung
Lieferung
Vertrauenswürdige Partner:
DHLUPSTNTFedEx
Internationaler Versand
Persönlicher Ansprechpartner
Sendungsverfolgung in Echtzeit

Beschreibung

The WAGO 222-412 is a two-conductor splicing connector designed for efficient and secure electrical connections. Featuring a gray housing and operating levers, it accommodates a wide range of conductor types and sizes, making it versatile for various applications. The connector supports solid and stranded conductors from 0.08 to 2.5 mm² (28 to 12 AWG) and fine-stranded conductors up to 4 mm² (12 AWG). It is rated for a nominal voltage of 400 V and a rated current of 32 A, ensuring reliable performance in demanding environments. The connector operates effectively in ambient temperatures up to 40°C, providing flexibility in different settings. Its compact dimensions—12.4 mm in width, 14.5 mm in height, and 20.5 mm in depth—allow for easy integration into tight spaces. The WAGO 222-412 is an ideal solution for professionals seeking a reliable and versatile splicing connector for their electrical projects.

Technische Daten

Gewicht
0,01 kg
Produkttyp
Splicing Connector
Conductor Type
Solid and Stranded
Leiterquerschnitt
0.08 to 2.5 mm² (28 to 12 AWG) for solid and stranded; up to 4 mm² (12 AWG) for fine-stranded
Nominal Voltage
400 V
Rated Current
32 A
Betriebstemperatur
Up to 40°C
Abmessungen
12.4 mm (W) x 14.5 mm (H) x 20.5 mm (D)
Gehäusefarbe
Gray
Betätigungstyp
Lever
Brennbarkeit gemäß UL94
V0
Brandlast
0.067 MJ
