Wago 750-603

Produktbild: Wago 750-603 750-603, 1
SKU750-603
HerstellerWago
KategorieIndustrielle Automatisierungsteile
6 Monate Garantie
Verfügbar (1-2 Tage): 8 Stück
Zustand wählen
Menge
1
Nettopreis (1 Stk.):
62,13PLN
Prüfen Sie vor der Bestellung, ob das Teil zu Ihrem Gerät passt.
Kostenlose Beratung
Lieferung
Vertrauenswürdige Partner:
DHLUPSTNTFedEx
Internationaler Versand
Persönlicher Ansprechpartner
Sendungsverfolgung in Echtzeit

Beschreibung

The WAGO 750-603 is a potential distribution module designed for the WAGO I/O System 750/753 series. This module provides an 8-way 24 V potential distribution, facilitating efficient power distribution across connected modules. It is mounted on a DIN-35 rail and features a light gray housing made of polycarbonate and polyamide 6.6, ensuring durability and reliability in industrial environments. The module operates within an ambient temperature range of 0°C to 55°C and has an ingress protection rating of IP20, making it suitable for various industrial applications. Its compact dimensions (12 mm width, 69.8 mm height, and 100 mm depth) allow for space-efficient integration into control cabinets. The 750-603 is CE marked, indicating compliance with European safety standards. This module is ideal for applications requiring reliable and efficient potential distribution in automation systems.

Technische Daten

Stromversorgung
24 VDC
Montageart
DIN-35 rail
Housing Material
Polycarbonate, Polyamide 6.6
Betriebstemperatur
0°C to 55°C
Schutzart
IP20
Abmessungen
12 mm x 69.8 mm x 100 mm
Gewicht
45.5 g
Conductor Size
0.08 to 2.5 mm² / 28 to 14 AWG mm² / AWG
Strip Length
8 to 9 mm / 0.31 to 0.35 inches mm / inches
