Eaton EU5C-SWD-DP

Name: EU5C-SWD-DP
Brand: Eaton
SKU: EU5C-SWD-DP
Price: 1081.75 PLN
Availability: InStock

SKUEU5C-SWD-DP

ManufacturerEaton

CategoryIndustrial automation components

6-month warranty

Available (1-2 days): 1 units

Select Condition

Quantity

Net price (1 pc.):

1 081,75PLN

Before ordering, make sure the part fits your device.

Free consultation

Delivery

Trusted partners:

International shipping

Dedicated account manager

Real-time tracking

Description

The Eaton EU5C-SWD-DP is a SmartWire-DT gateway module designed to integrate up to 58 SmartWire-DT modules with PROFIBUS-DP fieldbus systems. This device facilitates seamless communication between SmartWire-DT modules and programmable logic controllers (PLCs), enhancing automation processes in industrial settings. Key features include automatic baud rate detection ranging from 9.6 Kbit/s to 12 Mbit/s, a 9-pole SUB-D socket for fieldbus connection, and a separate serial diagnostics interface (RJ45) for maintenance and troubleshooting. The module is compliant with IEC/EN 61131-2 and EN 50178 standards, ensuring reliable performance in various industrial environments. Its compact dimensions (35 mm width, 90 mm height, 127 mm depth) and lightweight design (0.16 kg) allow for flexible installation options, including horizontal or vertical mounting on top-hat rails (IEC/EN 60715, 35 mm) or via screw fixing using optional brackets. The EU5C-SWD-DP is UL Listed and CSA Certified, meeting international safety and quality standards. This gateway module is ideal for applications requiring robust and efficient communication between field devices and control systems, such as in manufacturing automation, process control, and machinery monitoring.

Specifications

Weight	0.10 kgs
Product Type	SmartWire-DT Gateway Module
Fieldbus Interface	PROFIBUS-DP
Maximum Modules Supported	58 modules
Baud Rate Range	9.6 Kbit/s to 12 Mbit/s
Mounting Options	Horizontal or Vertical
Dimensions (W x H x D)	35 x 90 x 127 mm
Weight	0.16 kg
Compliance	IEC/EN 61131-2, EN 50178
Certifications	UL Listed, CSA Certified
