Festo ADVU-50-30-A-P-A

SKUADVU-50-30-A-P-A

ManufacturerFesto

CategoryIndustrial automation components

6-month warranty

Available (1-2 days): 1 units

Select Condition

Quantity

Net price (1 pc.):

166,64PLN

Before ordering, make sure the part fits your device.

Free consultation

Delivery

Trusted partners:

International shipping

Dedicated account manager

Real-time tracking

Description

The Festo ADVU-50-30-A-P-A is a compact double-acting pneumatic cylinder designed for precise linear motion in industrial automation applications. With a stroke length of 30 mm and a piston diameter of 50 mm, it delivers reliable performance in confined spaces. The cylinder operates at an ambient temperature range of -20°C to 80°C and is suitable for use with compressed air as per ISO 8573-1:2010 [7:4:4]. It features elastic cushioning rings at both ends to ensure smooth operation and reduce impact forces. The mounting position is flexible, allowing installation in various orientations to fit specific application requirements. The theoretical force at 6 bar pressure is 1,178 N during the advance stroke and 1,057 N during the retract stroke, providing sufficient power for a wide range of tasks. The cylinder is constructed with a galvanized steel flange and a cover made of wrought aluminum alloy, ensuring durability and resistance to moderate corrosion stress. The pneumatic connection is G1/8, compatible with standard fittings for easy integration into existing systems. This model is ideal for applications requiring compact size without compromising on performance, such as material handling, assembly processes, and automation systems where space constraints are a concern.

Specifications

Product Type	Sensor
Stroke Length	30 mm
Piston Diameter	50 mm
Operating Pressure	0.8 to 10 bar
Theoretical Force (Advance Stroke)	1,178 N
Theoretical Force (Retract Stroke)	1,057 N
Ambient Temperature Range	-20 to 80 °C
Mounting Position	Any
Cushioning	Elastic cushioning rings/pads at both ends
Pneumatic Connection	G1/8
