Festo AEVC-12-10-P

SKUAEVC-12-10-P

ManufacturerFesto

CategoryIndustrial automation components

12-month warranty

Available (1-2 days): 5 units

Select Condition

Quantity

Net price (1 pc.):

91,94PLN

Before ordering, make sure the part fits your device.

Free consultation

Delivery

Trusted partners:

International shipping

Dedicated account manager

Real-time tracking

Description

The Festo AEVC-12-10-P is a compact, single-acting short-stroke cylinder designed for precise linear motion in automation applications. With a piston diameter of 12 mm and a stroke length of 10 mm, it delivers a spring return force of 4 N when the piston rod is retracted. The cylinder operates at an ambient temperature range of -20°C to 80°C and is suitable for use with compressed air according to ISO 8573-1:2010 [7:4:4]. It features elastic cushioning rings/plates at both ends to ensure smooth operation and has a theoretical force of 59.3 N at 0.6 MPa (6 bar) during the advance stroke. The AEVC-12-10-P is constructed with a wrought aluminium alloy housing and piston rod, both anodized for enhanced durability. The pneumatic connection is M5, and the cylinder is RoHS-compliant, ensuring it meets environmental standards. This cylinder is ideal for applications requiring precise and reliable linear actuation in confined spaces.

Specifications

Weight	1.20 kgs
Stroke	10 mm
Piston Diameter	12 mm
Spring Return Force	4 N
Operating Pressure	1.5 - 10 bar
Ambient Temperature	-20°C to 80°C
Material Cover	Wrought aluminium alloy, anodized
Material Seals	NBR, TPE-U(PU)
Material Housing	Wrought aluminium alloy, anodized
Material Piston Rod	High-alloy steel
Pneumatic Connection	M5
RoHS Compliant	Yes
