Festo CPE14-M1CH-5J-1/8

Name: CPE14-M1CH-5J-1/8
Brand: Festo
SKU: CPE14-M1CH-5J-18
Price: 373.51 PLN
Availability: InStock

SKUCPE14-M1CH-5J-18

ManufacturerFesto

CategoryIndustrial automation components

12-month warranty

Available (1-2 days): 2 units

Select Condition

Quantity

Net price (1 pc.):

373,51PLN

Before ordering, make sure the part fits your device.

Free consultation

Delivery

Trusted partners:

International shipping

Dedicated account manager

Real-time tracking

Description

The Festo CPE14-M1CH-5J-1/8 is a compact solenoid valve designed for efficient control of compressed air in industrial automation systems. This valve features a 5/2 bistable function, allowing for precise switching between two positions, and is electrically actuated for reliable operation. With a construction width of 14 mm, it is suitable for applications where space is limited. The valve offers a standard nominal flow rate of 800 l/min, ensuring adequate air flow for various pneumatic processes. It operates at a voltage of 24V DC and supports an operating pressure range from 2 bar to 8 bar, providing versatility across different system requirements. The valve is constructed with a piston gate design, known for its durability and performance. It holds certifications including c UL us - Recognized (OL) and DNV-TAA000032X, indicating compliance with international standards. The degree of protection is IP65/IP67, ensuring reliable performance in harsh environments. The nominal size is 6 mm, and the valve includes an exhaust-air function with a flow control option, allowing for controlled exhaust in the system. The sealing principle is soft, and the mounting position is optional, offering flexibility in installation. A manual override is available, with detenting via accessory and non-detenting options. The valve is pilot actuated with internal pilot air supply, and the flow direction is non-reversible. The valve position code is an inscription label holder, and it features overlap lap. The switching time reversal is 12 ms, with a duty cycle of 100%. The maximum positive test pulse with a 0 signal is 1200 µs, and the maximum negative test pulse with a 1 signal is 900 µs. The characteristic coil data for 24 V DC is 1.28 W. This solenoid valve is ideal for applications requiring precise control of compressed air, such as in automation systems, machinery, and process control.
