Festo DSN-16-25-P

Festo DSN-16-25-P dsn-16-25-p product image 1
SKUDSN-16-25-P
ManufacturerFesto
CategoryIndustrial automation components
12-month warranty
Available (1-2 days): 3 units
Select Condition
Quantity
1
Net price (1 pc.):
550,49PLN
Before ordering, make sure the part fits your device.
Free consultation
Delivery
Trusted partners:
DHLUPSTNTFedEx
International shipping
Dedicated account manager
Real-time tracking
Description
Specifications
Downloads
FAQ
Applications
Related

Description

The Festo DSN-16-25-P is a double-acting pneumatic cylinder designed for precise linear motion in industrial automation applications. With a 16 mm piston diameter and a 25 mm stroke length, it delivers a theoretical force of 120.6 N during the advance stroke and 103.7 N during the return stroke at 6 bar operating pressure. The cylinder features flexible cushioning rings at both ends to minimize impact and reduce noise. It operates within a pressure range of 1 to 10 bar and is suitable for ambient temperatures between -20°C and 80°C. The DSN-16-25-P conforms to ISO 6432 and CETOP RP 52 P standards, ensuring compatibility with various mounting options. Its M6 piston rod thread and M5 pneumatic connection facilitate easy integration into existing systems. This cylinder is ideal for applications requiring compact size and reliable performance in linear actuation tasks.

Specifications

Weight
0.18 kgs
Stroke Length
25 mm
Piston Diameter
16 mm
Theoretical Force (Advance Stroke)
120.6 N
Theoretical Force (Return Stroke)
103.7 N
Operating Pressure
1 to 10 bar
Ambient Temperature
-20 to 80 °C
Mounting Position
Any
Piston Rod Thread
M6
Pneumatic Connection
M5
Cushioning
Flexible cushioning rings at both ends

Downloads

Download product information
