Festo LRMA-QS-4

Festo LRMA-QS-4 lrma-qs-4 product image 1
SKULRMA-QS-4
ManufacturerFesto
CategoryIndustrial automation components
12-month warranty
Available (1-2 days): 1 units
Select Condition
Quantity
1
Net price (1 pc.):
109,18PLN
Before ordering, make sure the part fits your device.
Free consultation
Delivery
Trusted partners:
DHLUPSTNTFedEx
International shipping
Dedicated account manager
Real-time tracking
Description
Specifications
Downloads
FAQ
Applications
Related

Description

The Festo LRMA-QS-4 is a pneumatic pressure regulator designed to maintain a constant output pressure with secondary exhaust. It features QS-4 pneumatic connections on both ports and is mounted via a through hole. The regulator offers a standard nominal flow rate of 50 l/min and operates within an inlet pressure range of 0 to 9 bar. Its ambient temperature range spans from 0 to 60 °C. Constructed with a PBT-reinforced housing, it utilizes compressed air as the operating medium, adhering to ISO 8573-1:2010 [7:-:-] standards. The actuator is secured with a knurled screw and lock nut, allowing for any mounting position. The design incorporates a directly-controlled piston regulator with a continuous compressed air supply. A pressure gauge is included for monitoring, and the pressure regulation range is between 1 and 8 bar. The product weighs 45 grams, with the threaded plug made of nickel-plated brass and the threaded seal composed of PTFE.

Specifications

Weight
0.30 kgs
Flow Rate
50 L/min
Measurement Range
1 - 8
Inlet Pressure
0 to 9 bar
Ambient Temperature
0 to 60 °C
Housing Material
PBT-reinforced
Operating Medium
Compressed air
Pressure Regulation Range
1 - 8 bar
Product Weight
45 g
