Festo VMPA-KMS1-24-5

Name: VMPA-KMS1-24-5
Brand: Festo
SKU: VMPA-KMS1-24-5
Price: 224.1 PLN
Availability: InStock

SKUVMPA-KMS1-24-5

ManufacturerFesto

CategoryIndustrial automation components

12-month warranty

Available (1-2 days): 3 units

Select Condition

Quantity

Net price (1 pc.):

224,10PLN

Before ordering, make sure the part fits your device.

Free consultation

Delivery

Trusted partners:

International shipping

Dedicated account manager

Real-time tracking

Description

The Festo VMPA-KMS1-24-5 is a pre-assembled connecting cable designed for multi-pin connections to valve manifolds in industrial automation systems. This 5-meter cable features a 25-pin Sub-D connector on one end and open-ended wires on the other, facilitating direct field wiring. It operates within a DC voltage range of 0 to 30 V, with a nominal operating voltage of 24 V, and supports a current rating of up to 3 A. The cable is constructed with 25 x 0.34 mm² conductors, encased in a PVC sheath with a diameter of 11.4 mm, and is suitable for flexible installations with a minimum bending radius of 112 mm. Designed to meet DIN 41652 standards, the VMPA-KMS1-24-5 ensures reliable and secure connections in various industrial applications.

Specifications

Weight	0.91 kgs
Cable Length	5 m
DC Operating Voltage Range	0 V to 30 V
Nominal Operating Voltage DC	24 V
Current Rating	3 A
Number of Conductors	25
Conductor Size	0.34 mm²
Cable Diameter	11.4 mm
Minimum Bending Radius (Fixed Installation)	44.8 mm
Minimum Bending Radius (Flexible Installation)	112 mm
Stopień ochrony	IP65
Cable Sheath Material	PVC
