Festo VMPA2-M1H-MS-PI

SKUVMPA2-M1H-MS-PI

ManufacturerFesto

CategoryIndustrial automation components

6-month warranty

Available (1-2 days): 3 units

Select Condition

Quantity

Net price (1 pc.):

174,56PLN

Before ordering, make sure the part fits your device.

Free consultation

Delivery

Trusted partners:

International shipping

Dedicated account manager

Real-time tracking

Description

The Festo VMPA2-M1H-MS-PI is a 5/2-way monostable solenoid valve designed for efficient control of compressed air in industrial automation systems. This valve features a 20 mm valve size and operates with an electrical actuation type. It offers a standard nominal flow rate ranging from 670 to 840 l/min, depending on the specific model variant. The operating pressure spans from -0.09 MPa to 0.8 MPa (-0.9 bar to 8 bar), accommodating various industrial applications. Constructed with a piston gate design, the valve utilizes a mechanical spring for reset. It is certified with c UL us - Recognized (OL) and has an ingress protection rating of IP65, ensuring durability and reliability in demanding environments. The valve is suitable for vacuum applications and features a signal status display for operational monitoring. With a maximum switching frequency of 2 Hz, it is suitable for applications requiring moderate switching cycles. The valve is compatible with compressed air as per ISO 8573-1:2010 [7:4:4] standards, and operation with oil lubrication is possible, which may be required for certain applications. This solenoid valve is ideal for applications requiring precise control of compressed air flow and direction, such as in automated machinery, process control systems, and other industrial automation processes.

Specifications

Weight	0.05 kgs
Torque	0.65 NM
Measurement Range	0.9 - 8
Product Type	Valve
Valve Function	5/2-way monostable
Actuation Type	Electrical
Valve Size	20 mm
Normal Nominal Flow Rate	670-840 l/min
Operating Pressure	-0.09 to 0.8 MPa (-0.9 to 8 bar)
Construction Set Up	Piston gate valve
Reset Mode	Mechanical spring
Certification	c UL us - Recognized (OL)
Stopień ochrony	IP65
Mounting Position	Any
Manual Override	Detenting, Non-detenting
Type of Control	Pilot-controlled
