| Weight | 0.23 kgs |
| Product Type | High-Speed Counter Module |
| Product Series | MELSEC-A Series |
| Input Signal Type | 1-phase and 2-phase |
| Input Voltage | 5/12/24 VDC |
| Maximum Counting Speed | 50,000 pps (1-phase), 7,000 pps (2-phase) |
| Counter Range | 32-bit binary (-2,147,483,648 to 2,147,483,647) |
| Preset Counter Function | UP/DOWN preset counter and ring counter |
| External Input Voltage | 5/12/24 VDC |
| External Output Voltage | 12/24 VDC |
| External Output Current | 0.1 A/point, 0.8 A/common |
| Internal Current Consumption | 0.35 A (5 VDC) |
