Omron C200H-OC226

Name: C200H-OC226
Brand: Omron
SKU: C200H-OC226
Price: 574.63 PLN
Availability: InStock

SKUC200H-OC226

ManufacturerOmron

CategoryIndustrial automation components

6-month warranty

Available (1-2 days): 2 units

Select Condition

Quantity

Net price (1 pc.):

574,63PLN

Before ordering, make sure the part fits your device.

Free consultation

Delivery

Trusted partners:

International shipping

Dedicated account manager

Real-time tracking

Description

The Omron C200H-OC226 is a 16-point relay output module designed for the C200H series programmable logic controllers (PLCs). It provides efficient switching capabilities for industrial automation systems, featuring a maximum switching capacity of 2 A at 250 V AC (cosφ = 1), 2 A at 250 V AC (cosφ = 0.4), and 2 A at 24 V DC (8 A per unit). The module ensures reliable operation with a minimum switching capacity of 10 mA at 5 V DC. Equipped with a G6R-1 relay (24 V DC) with a socket, it offers a service life of 300,000 electrical operations and 10,000,000 mechanical operations. The C200H-OC226 boasts quick response times, with both ON and OFF response times capped at 15 ms. It supports one circuit with 16 points in common, allowing up to eight points to be ON simultaneously. The module consumes a maximum of 30 mA at 5 V DC and 90 mA at 26 V DC when eight points are ON simultaneously. With a compact design, it weighs approximately 0.48 kg (1.06 lbs), facilitating easy integration into control panels. This module is ideal for applications requiring reliable and swift relay output operations within the Omron C200H PLC system.

Specifications

Weight	0.46 kgs
Napięcie zasilania	24 V
Product Type	Module
Signal Type	24
I/O Configuration	16
Signal Level	24 V
Relay Specifications	250 VAC
Current	2 A
Frequency	50 - 60 HZ
Component Specifications	oc226
I/O Channels	16 channels
Power Supply Type	DC
