Schneider Electric DF103

Schneider Electric DF103 df103 product image 1
SKUDF103
ManufacturerSchneider Electric
CategoryIndustrial automation components
6-month warranty
Available (1-2 days): 2 units
Select Condition
Quantity
1
Net price (1 pc.):
80,45PLN
Before ordering, make sure the part fits your device.
Free consultation
Delivery
Trusted partners:
DHLUPSTNTFedEx
International shipping
Dedicated account manager
Real-time tracking
Description
Specifications
Downloads
FAQ
Applications
Related

Description

The Schneider Electric DF103 is a 3-pole fuse carrier designed for the TeSys DF range, accommodating fuse sizes of 10x38 mm. It supports a rated operational current of 32A and is suitable for both AC and DC applications up to 690V. The device features a toggle padlockable control type and is compatible with DF2CA and DF2CN fuse cartridges. Designed for easy DIN rail mounting, it offers a dual-position locking system for secure installation. The DF103 complies with international standards, including IEC 60947-3 and IEC 60269-2, and is certified by IEC, UL, CSA, CCC, and EAC. Its rated insulation voltage is 1000V AC, with a rated impulse withstand voltage of 6kV, and it can withstand short-circuit currents up to 120kA at 400V. The fuse carrier has a maximum power dissipation of 3W.

Specifications

Weight
0.45 kgs
Current
32 A
Relay Specifications
32 A
Product Type
Fuse Carrier
Product Family
TeSys DF
Rated Operational Voltage
690V
Fuse Size
10x38 mm
Control Type
Toggle padlockable
Typ montażu
DIN Rail
Standards Complied
IEC 60947-3, IEC 60269-2, UL 4248-1, CSA C22.2 No 4248-1, EN 45545-2: R22 HL2
Rated Insulation Voltage
1000V
Rated Impulse Withstand Voltage
6kV
Short-Circuit Withstand
120kA at 400V kA
