| Weight | 0.15 kgs |
| Product Type | Module |
| Signal Level | 10 V |
| Number of Output Channels | 8 channels |
| Output Type | Current (0...20 mA, 4...20 mA), Voltage (±10 V) |
| Conversion Time | 5 ms |
| Measurement Resolution | 1.28 mV (±10 V), 2.56 µA (0...20 mA, 4...20 mA) |
| Electrical Connection | SUB-D 25 connector |
| Isolation Between Channels | Common point |
| Protection Type | Short-circuit and overload protection |
| Output Voltage Limits | ≤ 30 V |
| Operating Temperature Range | 0 to 60 °C |
| Storage Temperature Range | -25 to 70 °C |
