Sick CS84-P1112

Name: CS84-P1112
Brand: Sick
SKU: CS84-P1112
Price: 1718.14 PLN
Availability: InStock

SKUCS84-P1112

ManufacturerSick

CategoryIndustrial automation components

6-month warranty

Available (1-2 days): 1 units

Select Condition

Quantity

Net price (1 pc.):

1 718,14PLN

Before ordering, make sure the part fits your device.

Free consultation

Delivery

Trusted partners:

International shipping

Dedicated account manager

Real-time tracking

Description

The SICK CS84-P1112 is a compact color sensor from the CS8 series, designed for precise color detection in industrial automation applications. With dimensions of 30.4 mm x 80 mm x 53 mm, it features a sensing distance of up to 12.5 mm, suitable for applications requiring close-range color recognition. The sensor utilizes RGB LED light sources with wavelengths of 640 nm, 525 nm, and 470 nm, ensuring accurate color detection across a broad spectrum. Its vertical light spot size is 2 mm x 4 mm, ideal for detecting small color variations. The CS84-P1112 operates with a supply voltage between 10 V DC and 30 V DC, consuming less than 120 mA, making it energy-efficient for continuous operation. It offers adjustable switching frequencies of 0.5 kHz, 1 kHz, and 3.5 kHz, accommodating various application requirements. The sensor's PNP switching output is capable of handling up to 100 mA, suitable for direct integration into control systems. Designed for durability, the CS84-P1112 has an IP67 enclosure rating, ensuring protection against dust and water ingress, and operates effectively within a temperature range of -10°C to +55°C. Its metal housing provides robust protection in industrial environments. The sensor is equipped with a teach-in button for easy configuration, supporting static 1-point teach-in mode for straightforward setup. These features make the SICK CS84-P1112 an excellent choice for applications requiring reliable and precise color detection in challenging industrial settings.

Specifications

Weight	0.45 kgs
Dimensions (W x H x D)	30.4 x 80 x 53 mm
Sensing Distance	≤ 12.5 mm
Light Source	LED, RGB
Wavelengths	640 nm, 525 nm, 470 nm
Light Spot Size	2 x 4 mm
Napięcie zasilania	10 to 30 V DC
Current Consumption	< 120 mA
Switching Frequency	0.5 kHz, 1 kHz, 3.5 kHz
Output Current	≤ 100 mA
Enclosure Rating	IP67
Operating Temperature	-10 to +55 °C
Housing Material	Metal, zinc diecast
