Siemens 3UG4622-1AA30

Siemens 3UG4622-1AA30 3ug4622-1aa30 product image 1
SKU3UG4622-1AA30
ManufacturerSiemens
CategoryIndustrial automation components
6-month warranty
Available (1-2 days): 2 units
Select Condition
Quantity
1
Net price (1 pc.):
212,44PLN
Before ordering, make sure the part fits your device.
Free consultation
Delivery
Trusted partners:
DHLUPSTNTFedEx
International shipping
Dedicated account manager
Real-time tracking

Description

The Siemens 3UG4622-1AA30 is a digital current monitoring relay designed for precise overcurrent and undercurrent detection in single-phase AC/DC circuits. Operating within a current range of 0.05 to 10 A, it offers adjustable settings for overshoot and undershoot thresholds, with a delay time adjustable from 0.1 to 20 seconds. The device features a hysteresis range from 0.01 to 5 A, ensuring stable operation by preventing rapid switching due to minor current fluctuations. It is powered by a 24 V AC/DC supply and is suitable for both AC and DC applications without electrical isolation to the measuring circuit. The relay includes one changeover contact, which can be configured with or without a fault buffer, and utilizes screw terminals for secure wiring. The 3UG4622-1AA30 is part of Siemens' SIRIUS 3UG4 series and is intended for DIN rail mounting, with dimensions of 22.5 mm in width, 92 mm in height, and 91 mm in depth. It is rated for an ambient temperature range of -25 to +60°C during operation and -40 to +85°C during storage. This model is a successor to the 3UG3522-1AC.. series.

Specifications

Weight
1.36 kgs
Product ID
3UG4622-1AA30
AL Field
N
Aluminium Weight
0
Argent Weight
0
Customs Tariff Code
85364190
Compliance
Produkt zgdony z RoHS od: 01.05.2012
Configurable Product
False
Copper Weight
0
Country of Origin
DE
EAN
4011209642416.0
ECCN
N
eClass 6
27-37-18-02
eClass 7.1
27-37-18-02
eClass 8
27-37-18-02
eClass Version 9
27-37-18-02
eClass Version 9.1
27-37-18-02
ETIM 7
EC001440
Group Classification Key
R711
List of Characteristics
CC-IC10
Metals Coefficient
LAO-----
Quantity in Package
1
Packaging Length
99,00
Packaging Width
29,00
Packaging Height
107,00
Packaging Size
MM
Product Description
CYFROWY PRZEKAŹNIK KONTROLI PRĄDU 1-FAZ., ZAKRES OD 0,05 DO 10 A, PRZEKROCZENIE GÓRNEJ I DOLNEJ GRANICY, NAPIĘCIE STEROWNICZE 24V AC/DC, OPÓŹNIENIE WYZWOLENIA 01-20s, HISTEREZA 0,01A-5A; STYKI 1CO; PRZYŁACZE ŚRUBOWE, ZAMIENNIK DLA 3UG3522-1AC..
Part Number
5885
Comparative Metals Coefficient
01.05.2012
REACH
Lead CAS-Nr. 7439-92-1; Lead monoxide (lead oxide) lblREACHCasNo7368
Unit of Measure
ST
UPC
754554930589.0
