Siemens 6ES7137-6AA01-0BA0

Siemens 6ES7137-6AA01-0BA0 6es7137-6aa01-0ba0 product image 1
SKU6ES7137-6AA01-0BA0
ManufacturerSiemens
CategoryIndustrial automation components
12-month warranty
Available (1-2 days): 65 units
Select Condition
Quantity
1
Net price (1 pc.):
1 517,02PLN
Before ordering, make sure the part fits your device.
Free consultation
Delivery
Trusted partners:
DHLUPSTNTFedEx
International shipping
Dedicated account manager
Real-time tracking
Description
Specifications
Downloads
FAQ
Applications
Related

Description

The Siemens 6ES7137-6AA01-0BA0 is a communication module designed for the SIMATIC ET 200SP system, enabling serial connections via RS-422, RS-485, and RS-232 interfaces. It supports protocols such as Freeport, 3964 (R), USS, and MODBUS RTU, functioning as both master and slave with a maximum transmission rate of 250 Kbit/s. This module is compatible with BaseUnit (BU) type A0 and is supplied as a single unit. It operates with a rated DC voltage of 24 V, with permissible ranges between 19.2 V and 28.8 V, and features reverse polarity protection. The typical current consumption is 31 mA, with a maximum of 35 mA, and a typical power loss of 0.7 W. The module offers 8 bytes of input address space, expandable to 32 bytes in performance mode, and 0 bytes of output address space, expandable to 32 bytes in performance mode. It includes automatic encoding and a mechanical coding element of type D. The module supports RS-485, RS-422, and RS-232 interfaces, with maximum transmission rates of 250 kbit/s, 115.2 kbit/s, and 115.2 kbit/s respectively. The maximum cable length for RS-485 and RS-422 is 1,200 meters, while for RS-232, it is 15 meters. The module operates within an ambient temperature range of -30°C to 60°C for horizontal installation and -30°C to 50°C for vertical installation, with a maximum installation altitude of 5,000 meters above sea level. It is suitable for decentralized operation with SIMATIC S7-300, S7-400, S7-1200, and S7-1500 systems.

Specifications

Weight
0.01 kgs
Compliance
Produkt zgdony z RoHS od: 30.04.2021
Customs Tariff Code
85176200
EAN
4047623411598.0
Quantity in Package
1
Product ID
6ES7137-6AA01-0BA0
AL Field
N
Configurable Product
False
Country of Origin
DE
ECCN
9N9999
eClass 6
27-24-26-08
eClass 7.1
27-24-26-08
eClass 8
27-24-26-08
eClass Version 9
27-24-26-08
eClass Version 9.1
27-24-26-08
ETIM 7
EC001604
Group Classification Key
R151
List of Characteristics
ST76
Packaging Length
7,80
Packaging Width
6,80
Packaging Height
2,40
Packaging Size
CM
Product Description
SIMATIC ET 200SP, CM PTP communication module for serial connection RS-422, RS-485 and RS-232, freeport, 3964 (R), USS, MODBUS RTU master, slave, max. 250 Kbit/s, suitable for BU type A0, pack quantity: 1 unit
Part Number
6ES7137-6AA01-0BA0
Comparative Metals Coefficient
30.04.2021
REACH
Silicic acid, lead salt lblREACHCasNo4420; 4,4'-isopropylidenediphenol (Bisphenol A, BPA) CAS-Nr. 80-05-7
Unit of Measure
ST
Manufacturer
Siemens
Category
Podzespoły automatyki przemysłowej
