Siemens 6ES7231-7PC22-0XA0

Siemens 6ES7231-7PC22-0XA0 6es7231-7pc22-0xa0 product image 1
SKU6ES7231-7PC22-0XA0
ManufacturerSiemens
CategoryIndustrial automation components
No warranty
Available: 1 units
Select Condition
Quantity
1
Net price (1 pc.):
Before ordering, make sure the part fits your device.
Free consultation
Delivery
Trusted partners:
DHLUPSTNTFedEx
International shipping
Dedicated account manager
Real-time tracking
Description
Specifications
Downloads
FAQ
Applications
Related

Description

The Siemens 6ES7231-7PC22-0XA0 is an analog input module designed for the SIMATIC S7-200 series, specifically compatible with S7-22X CPUs. This module features four analog input channels capable of processing signals from various resistance thermometers, including Pt100, Pt200, Pt500, Pt1000, Pt10000, Ni100, Ni120, and Ni1000, as well as copper (Cu10) and 14 GOST resistance thermometers. It supports resistance measurements of 150, 300, and 600 ohms with a 15-bit resolution, including sign. The module operates with an input current of up to 60 mA from the load voltage L+ (without load) and up to 87 mA from the backplane bus (5 V DC). The power loss is typically 1.8 W, with an additional 1 mW for the sensor. The permissible input voltage for voltage input is up to 30 V DC, with specific limits for probes and sources. The loop resistance of the connecting cable is up to 20 ohms, with a maximum of 2.7 ohms for copper conductors. The module's dimensions are 71.2 x 80 x 62 mm, and it weighs approximately 210 grams.

Specifications

Weight
0.16 kgs
I/O Channels
4 AI
Component Specifications
pt100
Industrial System
s7-22x
I/O Configuration
4
