Siemens 6ES7422-1BH11-0AA0

Siemens 6ES7422-1BH11-0AA0 6es7422-1bh11-0aa0 product image 1
SKU6ES7422-1BH11-0AA0
ManufacturerSiemens
CategoryIndustrial automation components
12-month warranty
Available (1-2 days): 1 units
Select Condition
Quantity
1
Net price (1 pc.):
572,80PLN
Before ordering, make sure the part fits your device.
Free consultation
Delivery
Trusted partners:
DHLUPSTNTFedEx
International shipping
Dedicated account manager
Real-time tracking
Description
Specifications
Downloads
FAQ
Applications
Related

Description

The Siemens 6ES7422-1BH11-0AA0 is a digital output module from the SIMATIC S7-400 series, designed to provide 16 isolated digital outputs at 24 V DC, each capable of handling up to 2 A. This module is ideal for applications requiring reliable and efficient control of digital signals in industrial automation systems. Key features include: - **Supply Voltage:** 24 V DC, with permissible ranges from 20.4 V to 28.8 V. - **Input Current:** Maximum of 30 mA from the load voltage L+ (without load) and 160 mA from the backplane bus (5 V DC). - **Power Loss:** Approximately 5 W under typical operating conditions. - **Digital Outputs:** 16 outputs with short-circuit protection, electronically clocked, and a response threshold between 2.8 to 6 A. - **Output Voltage:** For signal "1," the minimum is L+ (-0.5 V). - **Output Current:** For signal "1," the rated value is 2 A, with permissible ranges from 5 mA to 2.4 A. For signal "0," the residual current is a maximum of 0.5 mA. - **Switching Frequency:** Up to 100 Hz with resistive loads and up to 0.1 Hz with inductive loads. - **Dimensions:** 25 mm (width) x 290 mm (height) x 210 mm (depth). - **Weight:** Approximately 600 g. This module is suitable for various industrial applications requiring robust and efficient digital output control.

Specifications

Weight
0.27 kgs
Product ID
6ES7422-1BH11-0AA0
AL Field
N
Customs Tariff Code
85389091
Compliance
Produkt zgdony z RoHS od: 01.03.2008
Configurable Product
False
Country of Origin
DE
EAN
4019169043045.0
ECCN
9N9999
eClass 6
27-24-22-04
eClass 7.1
27-24-22-04
eClass 8
27-24-22-04
eClass Version 9
27-24-22-04
eClass Version 9.1
27-24-22-04
ETIM 7
EC001419
Group Classification Key
R338
List of Characteristics
ST74
Quantity in Package
1
Packaging Length
29,50
Packaging Width
23,30
Packaging Height
3,80
Packaging Size
CM
Product Description
SIMATIC S7-400, moduł wyjść binarnych SM 422, izolacja optyczna, 16 wyjść, 24V DC, 2A
Part Number
4041
Comparative Metals Coefficient
01.03.2008
REACH
Lead CAS-Nr. 7439-92-1
Unit of Measure
ST
UPC
662643186208.0
Supply Voltage
24 V DC
Input Current
30 mA
Power Loss
5 W
Digital Outputs
16 outputs
Output Current
2 A
