Siemens 6ES7550-1AA01-0AB0

Siemens 6ES7550-1AA01-0AB0 6es7550-1aa01-0ab0 product image 1
SKU6ES7550-1AA01-0AB0
ManufacturerSiemens
CategoryIndustrial automation components
12-month warranty
Available (1-2 days): 42 units
Select Condition
Quantity
1
Net price (1 pc.):
2 568,58PLN
Before ordering, make sure the part fits your device.
Free consultation
Delivery
Trusted partners:
DHLUPSTNTFedEx
International shipping
Dedicated account manager
Real-time tracking
Description
Specifications
Downloads
FAQ
Applications
Related

Description

The Siemens 6ES7550-1AA01-0AB0 is a high-performance counter module designed for the SIMATIC S7-1500 series, offering precise counting and encoder signal processing capabilities. This module features two channels for 24 V incremental or pulse encoders, each equipped with three digital inputs and two digital outputs, facilitating efficient signal acquisition and control. It supports counting frequencies up to 200 kHz and counting rates up to 800 kHz with quadruple evaluation, ensuring rapid and accurate data processing. The module operates with a 24 V DC supply voltage, with permissible ranges from 19.2 to 28.8 V DC, and provides a common 24 V encoder supply with a maximum total current of 1 A across both channels. Designed for versatility, it supports various applications, including frequency measurement, cycle duration measurement, and position detection with incremental encoders. The module is suitable for integration into systems requiring high-speed counting and encoder signal processing, such as motion control and process automation. With a compact design measuring 19.4 x 16.1 x 4.7 cm and a net weight of 0.357 kg, it is engineered for easy integration into existing setups. Manufactured in Germany, the 6ES7550-1AA01-0AB0 adheres to stringent quality standards, ensuring reliable performance in industrial environments.

Specifications

Weight
0.45 kgs
Product ID
6ES7550-1AA01-0AB0
AL Field
N
Customs Tariff Code
85389091
Compliance
Produkt zgdony z RoHS od: 31.01.2021
Configurable Product
False
Country of Origin
DE
EAN
4047623411260.0
ECCN
9N9999
eClass 6
27-24-22-05
eClass 7.1
27-24-22-05
eClass 8
27-24-22-05
eClass Version 9
27-24-22-05
eClass Version 9.1
27-24-22-05
ETIM 7
EC001422
Group Classification Key
R151
List of Characteristics
ST73
Quantity in Package
1
Packaging Length
19,40
Packaging Width
16,10
Packaging Height
4,70
Packaging Size
CM
Product Description
SIMATIC S7-1500, TM count 2x 24 V counter module, 2 channels for 24 V incremental encoder or pulse encoder, 3 DI, 2 DQ per channel
Part Number
4502
Comparative Metals Coefficient
31.01.2021
REACH
Lead CAS-Nr. 7439-92-1
Unit of Measure
ST
UPC
195125170131.0
Weight
0,357 kg
Wymiary
19,4 x 16,1 x 4,7 cm
Napięcie zasilania
24 V DC
Zakres napięcia wejściowego
19,2 do 28,8 V DC
Maksymalny prąd zasilania enkodera
1 A
Częstotliwość liczenia
200 kHz
Szybkość liczenia
800 kHz
Liczba wejść cyfrowych na kanał
3 szt.
Liczba wyjść cyfrowych na kanał
2 szt.
