Siemens 6ES7972-0BB61-0XA0

Siemens 6ES7972-0BB61-0XA0 6es7972-0bb61-0xa0 product image 1
SKU6ES7972-0BB61-0XA0
ManufacturerSiemens
CategoryIndustrial automation components
12-month warranty
Available (1-2 days): 80 units
Select Condition
Quantity
1
Net price (1 pc.):
270,07PLN
Before ordering, make sure the part fits your device.
Free consultation
Delivery
Trusted partners:
DHLUPSTNTFedEx
International shipping
Dedicated account manager
Real-time tracking

Description

The Siemens 6ES7972-0BB61-0XA0 is a PROFIBUS bus connector designed for seamless integration into industrial automation systems. This connector facilitates the connection of PROFIBUS stations to the PROFIBUS bus cable, ensuring reliable data transmission at speeds ranging from 9.6 kbit/s to 12 Mbit/s. It features a 35-degree cable outlet and employs the FastConnect insulation displacement method, which simplifies and accelerates the installation process. The integrated 9-pin Sub-D connector provides a secure interface for network components or terminal equipment. Additionally, the connector includes a terminating resistor combination that can be activated via a slide switch, enhancing network stability. Constructed with a durable plastic enclosure, it offers protection class IP20, making it suitable for various industrial environments. The connector operates effectively within a temperature range of -25°C to +60°C during operation and can withstand storage and transport temperatures between -40°C and +70°C. Its compact dimensions of 15.8 mm in width, 54 mm in height, and 39.5 mm in depth, along with a net weight of 34 grams, allow for flexible installation in space-constrained areas. The 6ES7972-0BB61-0XA0 is part of Siemens' SIMATIC DP series, reflecting its commitment to high-quality industrial automation solutions.

Specifications

Weight
0.45 kgs
Product ID
6ES7972-0BB61-0XA0
Configurable Product
False
Country of Origin
DE
ECCN
N
eClass 6
27-26-07-03
eClass 7.1
27-44-01-01
eClass 8
27-44-01-01
eClass Version 9
27-44-01-01
eClass Version 9.1
27-44-01-01
ETIM 7
EC002636
Group Classification Key
R151
List of Characteristics
ST76
Packaging Length
7,80
Packaging Width
6,80
Packaging Height
3,20
Packaging Size
CM
Product Description
SIMATIC DP, Connection plug for PROFIBUS up to 12 Mbit/s 35 degree cable outlet, Insulation displacement method FastConnect, With PG receptacle 15.8x 54x 39.5 mm (BxHxD)
Comparative Metals Coefficient
02.02.2016
REACH
Lead monoxide (lead oxide) lblREACHCasNo7368
Unit of Measure
ST
Customs Tariff Code
85366990
EAN
4047623406884.0
Quantity in Package
1
Part Number
4059
UPC
804766281426.0
AL Field
N
Compliance
Produkt zgdony z RoHS od: 02.02.2016
