Siemens 6GK7542-5DX00-0XE0

Siemens 6GK7542-5DX00-0XE0 6gk7542-5dx00-0xe0 product image 1
SKU6GK7542-5DX00-0XE0
ManufacturerSiemens
CategoryIndustrial automation components
12-month warranty
Available (1-2 days): 1 units
Select Condition
Quantity
1
Net price (1 pc.):
2 580,08PLN
Before ordering, make sure the part fits your device.
Free consultation
Delivery
Trusted partners:
DHLUPSTNTFedEx
International shipping
Dedicated account manager
Real-time tracking
Description
Specifications
Downloads
FAQ
Applications
Related

Description

The Siemens 6GK7542-5DX00-0XE0 is a communication module designed to integrate Siemens S7-1500 series programmable logic controllers (PLCs) with PROFIBUS DP networks. This module facilitates seamless communication between S7-1500 PLCs and PROFIBUS DP devices, supporting both master and slave configurations. It enables S7 and PG/OP communication, data record routing, time-of-day synchronization, and diagnostic functions, enhancing the overall performance and reliability of industrial automation systems. Key features include a transfer rate of 9.6 kbit/s to 12 Mbit/s, a 9-pin Sub-D socket (RS485) interface, and a compact design measuring 35 mm in width, 142 mm in height, and 129 mm in depth. The module operates within an ambient temperature range of 0 to 40°C for vertical installation and up to 60°C for horizontally arranged busbars during operation. It requires a 15 V DC supply voltage and consumes approximately 0.2 A from the backplane bus, with a power loss of 3 W. The Siemens 6GK7542-5DX00-0XE0 is an essential component for establishing reliable and efficient communication in industrial automation applications, particularly where integration between S7-1500 PLCs and PROFIBUS DP networks is required.

Specifications

Weight
0.14 kgs
Interface Type
profibus
Industrial System
s7-1500
Product Type
Module
Transfer Rate
9.6 kbit/s to 12 Mbit/s
Supply Voltage
15 V DC
Power Loss
3 W
Ambient Temperature
0 to 40°C (vertical installation)
Ambient Temperature (Operating, Vertical Installation)
0 to 40 °C
Ambient Temperature (Operating, Horizontal Installation)
0 to 60 °C
Ambient Temperature (Storage)
-40 to +70 °C
Ambient Temperature (Transport)
-40 to +70 °C
Supply Voltage
15 V DC
Current Consumption
0.2 A
Power Loss
3 W
Dimensions
35 x 142 x 129 mm

Downloads

Download product information
