Wago 285-637

Wago 285-637 285-637 product image 1
SKU285-637
ManufacturerWago
CategoryIndustrial automation components
12-month warranty
Available (1-2 days): 4 units
Select Condition
Quantity
1
Net price (1 pc.):
69,92PLN
Before ordering, make sure the part fits your device.
Free consultation
Delivery
Trusted partners:
DHLUPSTNTFedEx
International shipping
Dedicated account manager
Real-time tracking

Description

The WAGO 285-637 is a 2-conductor ground terminal block designed for secure and efficient grounding in industrial automation systems. This terminal block accommodates wire gauges from 6 to 35 mm² (2 to 10 AWG) and features a spring-clamp connection for reliable wire retention. It is constructed with a green-yellow polyamide (PA66) housing, ensuring durability and compliance with UL94 V-0 flammability standards. The 285-637 is suitable for mounting on DIN 35 x 15 rails and includes integrated end plates with side and center markings for easy identification. Its compact dimensions—16 mm in width, 100 mm in length, and 53 mm in height from the upper edge of the DIN rail—make it ideal for applications where space is limited. This terminal block is rated for a continuous operating temperature range of -60°C to +105°C, making it suitable for various industrial environments. For detailed specifications and installation guidelines, refer to the manufacturer's datasheet.

Specifications

Wire Gauge Range
6 to 35 mm² (2 to 10 AWG)
Conductor Size Range
6 to 35 mm² (8 to 2 AWG)
Connection Type
Spring-clamp
Housing Material
Polyamide (PA66)
Mounting Type
DIN-35 rail
Marking Type
Side and center marking
Rated Current
125 A
Rated Voltage
1000 V
Color
Green-yellow
Product Type
2-conductor ground terminal block
