Wago 750-506

Wago 750-506 750-506 product image 1
SKU750-506
ManufacturerWago
CategoryIndustrial automation components
6-month warranty
Available (1-2 days): 33 units
Select Condition
Quantity
1
Net price (1 pc.):
99,07PLN
Before ordering, make sure the part fits your device.
Free consultation
Delivery
Trusted partners:
DHLUPSTNTFedEx
International shipping
Dedicated account manager
Real-time tracking

Description

The WAGO 750-506 is a 2-channel digital output module designed for industrial automation applications. Operating at 24 VDC with a maximum output current of 0.5 A per channel, it provides reliable control signals to connected actuators. The module features high-side switching and supports various load types, including resistive, inductive, and lamp loads. Diagnostics capabilities include detection of open circuits, short circuits, and overloads, with status indicators transmitted to the fieldbus coupler and displayed via LEDs. The module offers electrical isolation between field and system levels, ensuring protection against electrical faults. Its compact design allows for easy integration into existing automation systems, making it suitable for a wide range of industrial applications.

Specifications

Brand
WAGO
Part Number
750-506
Operating Voltage
24 VDC
Output Current per Channel
0.5 A
Switching Frequency (Max.)
5 kHz
Load Type
Resistive, Inductive, Lamp Load
Diagnostics
Open Circuit, Short Circuit, Overload
Field and System Isolation
500 V
Dimensions
12 mm x 100 mm
