Mitsubishi A0J2-E56DT

Produktbild: Mitsubishi A0J2-E56DT a0j2-e56dt, 1
SKUA0J2-E56DT
HerstellerMitsubishi
KategorieIndustrielle Automatisierungsteile
6 Monate Garantie
Verfügbar: 1 Stück
Zustand wählen
Menge
1
Nettopreis (1 Stk.):
Prüfen Sie vor der Bestellung, ob das Teil zu Ihrem Gerät passt.
Kostenlose Beratung
Lieferung
Vertrauenswürdige Partner:
DHLUPSTNTFedEx
Internationaler Versand
Persönlicher Ansprechpartner
Sendungsverfolgung in Echtzeit

Beschreibung

The Mitsubishi A0J2-E56DT is an I/O module from the MELSEC-A series, designed to expand the input and output capabilities of Mitsubishi's programmable logic controllers (PLCs). This module features 32 input points and 24 output points, accommodating both 12 VDC and 24 VDC systems. Each input point has a rated input current of approximately 3 mA, while each output point can handle a maximum load current of 0.5 A, with a total common current of up to 4 A. The module operates within a voltage range of 10.2 to 30 VDC, with a ripple ratio of within 5%. It is equipped with a surge suppressor (varistor) rated between 52 to 62 V to protect against voltage spikes. The A0J2-E56DT utilizes a 36-point terminal block connector (M3 × 6 screws) for external connections, supporting wire sizes from 0.75 to 2 mm². The module's external dimensions are 250 mm in height, 190 mm in width, and 41 mm in depth, with a weight of approximately 1.04 kg. This module is suitable for applications requiring reliable and efficient input/output processing in industrial automation systems.

Technische Daten

Eingangspunkte
32 points
Ausgangspunkte
24 points
Eingangsspannung
12/24 VDC
Ausgangsspannung
12/24 VDC
Eingangsstrom
3 mA
Ausgangsstrom
0.5 A
Surge Suppressor
Varistor (52 to 62 V)
Anschlussblock
36-point terminal block connector (M3 × 6 screws) points
Kabellänge
0.75 to 2 mm²
Abmessungen
250 x 190 x 41 mm
Gewicht
1.04 kg
