Beckhoff BK3120

Beckhoff BK3120 bk3120 product image 1
SKUBK3120
ManufacturerBeckhoff
CategoryIndustrial automation components
12-month warranty
Available: 1 units
Select Condition
Quantity
1
Net price (1 pc.):
Before ordering, make sure the part fits your device.
Free consultation
Delivery
Trusted partners:
DHLUPSTNTFedEx
International shipping
Dedicated account manager
Real-time tracking

Description

The Beckhoff BK3120 is a PROFIBUS Economy plus Bus Coupler designed to integrate Beckhoff Bus Terminals into a PROFIBUS network. It supports up to 64 Bus Terminals, expandable to 255 with K-bus extension, and facilitates the connection of up to 1020 digital and 64 analog peripheral signals. The BK3120 operates with automatic baud rate detection up to 12 Mbaud, ensuring adaptability to various network speeds. It features a D-sub 9-pin socket for the bus interface and requires a 24 V DC power supply. The device is housed in a compact polycarbonate enclosure suitable for mounting on a 35 mm DIN rail. It operates within a temperature range of -25°C to +60°C and complies with various international standards, including CE, UL, and ATEX.

Specifications

Weight
0.20 kgs
Component Specifications
bk3120
Interface Type
profibus
Weight
170 g
Number of Bus Terminals
64 (255 with K-bus extension) terminals
Digital Peripheral Signals
up to 1020 inputs/outputs signals
Analog Peripheral Signals
up to 64 inputs/outputs signals
Baud Rate
up to 12 Mbaud
Bus Interface
1 x D-sub 9-pin socket with shielding
Power Supply
24 V DC (-15%/+20%)
Operating Temperature
-25°C to +60°C
Housing Material
Polycarbonate material
