Festo ADVU-32-20-A-P-A

Name: ADVU-32-20-A-P-A
Brand: Festo
SKU: ADVU-32-20-A-P-A
Price: 103.43 PLN
Availability: InStock

SKUADVU-32-20-A-P-A

ManufacturerFesto

CategoryIndustrial automation components

12-month warranty

Available (1-2 days): 1 units

Select Condition

Quantity

Net price (1 pc.):

103,43PLN

Before ordering, make sure the part fits your device.

Free consultation

Delivery

Trusted partners:

International shipping

Dedicated account manager

Real-time tracking

Description

The Festo ADVU-32-20-A-P-A is a compact double-acting pneumatic cylinder designed for precise linear motion in industrial automation applications. With a stroke length of 20 mm and a piston diameter of 32 mm, it offers efficient performance in confined spaces. The cylinder operates at an ambient temperature range of -20°C to 80°C and is suitable for use with compressed air as per ISO 8573-1:2010 [7:4:4]. It features elastic cushioning rings/pads at both ends to ensure smooth operation and reduce impact forces. The piston rod end is equipped with an external thread (M10x1.25) for secure mounting. The cylinder's theoretical force at 6 bar pressure is 415 N during retraction and 483 N during extension, making it suitable for applications requiring moderate force output. The operating pressure range is between 0.8 bar and 10 bar, providing flexibility for various operational conditions. The cylinder is constructed with a wrought aluminum alloy cover and a high-alloyed stainless steel piston rod, ensuring durability and resistance to corrosion. Its compact design allows for installation in spaces up to 50% smaller than comparable ISO cylinders, making it ideal for applications where space is limited. The ADVU-32-20-A-P-A is part of Festo's ADVU series, known for its versatility and reliability in automation tasks.

Specifications

Weight	0.91 kgs
Stroke Length	20 mm
Piston Diameter	32 mm
Operating Pressure	0.8 to 10 bar
Theoretical Force (Retracting)	415 N
Theoretical Force (Extending)	483 N
Ambient Temperature Range	-20 to 80 °C
Mounting Position	Any
Cushioning	Elastic cushioning rings/pads at both ends
Piston Rod Thread	M10x1.25
Operating Medium	Compressed air as per ISO 8573-1:2010 [7:4:4]
Corrosion Resistance Class	2 - Moderate corrosion stress
