Siemens 4EP3600-5US

Siemens 4EP3600-5US 4ep3600-5us product image 1
SKU4EP3600-5US
ManufacturerSiemens
CategoryIndustrial automation components
6-month warranty
Available (1-2 days): 3 units
Select Condition
Quantity
1
Net price (1 pc.):
453,96PLN
Before ordering, make sure the part fits your device.
Free consultation
Delivery
Trusted partners:
DHLUPSTNTFedEx
International shipping
Dedicated account manager
Real-time tracking

Description

The Siemens 4EP3600-5US00 is a three-phase line reactor designed for frequency converters, operating at a rated voltage of 480 V and a frequency range of 50 to 60 Hz. It features a rated current of 25.2 A and a maximum current of 28 A, with a rated inductance of 0.503 mH. The reactor has a relative inductive voltage drop of 2% and a power loss of 37.4 W in the coil and 7.7 W in the iron core. It is housed in an IP00 enclosure and utilizes screw-type terminals for electrical connections. The device complies with EN 61558-2-20 standards and is UL/CSA recognized.

Specifications

Current
28 A
Manufacturer
Siemens
Signal Level
400 V
Relay Specifications
28 A
Operating Voltage
480 V
Maximum Current
28 A
Rated Inductance
0.503 mH
Inductive Voltage Drop
2 %
Power Loss in Coil
37.4 W
Power Loss in Iron Core
7.7 W
Enclosure Protection Class
IP00
Electrical Connection Type
Screw-type terminals
Compliance Standards
EN 61558-2-20, UL/CSA recognized
